Description
Model No.: | Power | LED QTY | LED Color | Beam Angle | Input Volt. |
BC-1072W-1.0M | 48W/24W | 24PCS | 2700K/3000K/4000K /5700K /RGB3in1/ RGBW4in1 DMX512 | 10*60°/10/25/45/60/ ASY | AC220V /DC24V |
BC-1072W-0.545M | 24W/12W | 12PCS | |||
BC-1072W-0.345M | 16W/8W | 8PCS |
Front Cover:Stainless steel SUS316
Housing: 12#Die-casting powder coated aluminum. T=60-80um.Adhesion of ISO class 1/ASTM class 4B high temperature painting.
Driver:Constant voltage input.Constant current output.
Glass:Step tempered glass.
Mounting sleeve:ABS
Dimmable: Triac/Dali/1-10V/PWM/DMX512.
Power Cable:H05RN-F 2×1.0mm2 L=0.5m(low voltage).
H05RN-F 3×1.0mm² L=0.5m(high voltage)
H05RN-F 2×1.0+F3×0.5mm² power cable L=0.5m(DC24V DMX512)
Working Temperature:-20 to 40°C.
