Description
Model No.: | Power | LED QTY | LED Color | Beam Angle | Input Volt. |
BC-UPL800306 | 7W | 3PCS | 2700K/3000K/4000K /5700K | 10°/15°/25° /30° /40° /60°/10°*45°/20°*65° | AC220V |
BC-UPL800308 | 7W | DC24V | |||
BC-UPL800103 | 3W/7W | 1PCS | 4°/6°/9° | AC220V | |
BC-UPL800108 | 7W | DC24V | |||
BC-UPL800110 | 7W | 5°/24° /38° （Lens） | AC220V /DC24V | ||
BC-UPL800111 | 7W | 10°/23° /38° （Reflector Cup） | |||
BC-UPL800309 | 7W | 3PCS | RGBW 4in1 DMX512 | 25°/40° /60°/10°*22° /12°*45°/15°*55° | DC24V |
Front Cover:Stainless steel SUS316
Housing: 12#Die-casting powder coated aluminum. T=60-80um.Adhesion of ISO class 1/ASTM class 4B high temperature painting.
Driver:Constant voltage input.Constant current output.
Glass:Step tempered glass.
Mounting sleeve:ABS
Dimmable: Triac/Dali/1-10V/PWM/DMX512.
Power Cable:H05RN-F 2×1.0mm2 L=0.5m(low voltage).
H05RN-F 3×1.0mm² L=0.5m(high voltage)
H05RN-F 2×1.0+F3×0.5mm² power cable L=0.5m(DC24V DMX512)
Working Temperature:-20 to 40°C.
