Description
Material Specifications
Housing: 12#Die-casting powder coated aluminum.T=60-80um. Adhesion of ISO class 1/ASTM class 48 high temperature painting
Front Cover: SUS316# stainless steel—Hard Chromeplated
Glass: Step Tempered glass.T=10mm
Lens: Optical lens, efficiency≥90%
LED Driver: Constant voltage input, Constant current output
Cable Gland: IP68 copper and nickel coated
Gasket: Tooling shaped seal
Mounting Sleeve:ABS
Working Temperature: -20 to 40℃
Power Cable: H05RN-F 2X1.0mm² L=0.5m(low voltage)
H05RN-F 3X0.75mm² L=0.5m(high voltage) MEANWELL DRIVER
H05RN-F 4X0.75mm² L=0.5m(RGB)
Dimmable : DALI Traic PWM 1-10V DMX512
